Blue Sea 7044 187 - Series Thermal Circuit Breaker - 100Amp

187 - Series Thermal Circuit Breakers - Panel Mount

100 Amp Circuit Breaker

PN:  7044

Features:

• Combines switching and circuit protection into a single device

• All components meet SAE J1171 external ignition protection requirements

• Clear, single lever operation

• "Trip Free" design cannot be held "ON" during fault current condition

• Waterproof

• Recessed mounting holes for clean appearance

• Self-trimming case eliminates the need for mounting panels or trim bezels

• Round case permits easy installation with standard sized hole saw

• Large clearance around terminal studs accept heavy gauge wire lugs

• Robust 5/16 terminals provide high torque connections

• Large lever with vertical/horizontal orientation provides indication of trip status

• Ignition protected - safe for installation aboard gasoline powered boats

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Specifications:

• Amperage: 100a
• Box Dimensions: 4"H x 5"W x 7"L WT: 0.5 lbs
• UPC: 632085170448
